DALI bus standard IEC62386-101, 102, 209
DALI-2 DT6 and DT8
Output Voltage 9-42Vdc
Output Current Range 100-500mA
Output Power Range 0,9-12W

Input voltage 12 - 24Vdc
Output voltage 12 - 24Vdc
Output 4x5A
LED Outputs 4x and Ouput signaal 1x
Constant Voltage driver

Input voltage 12 - 24Vdc
Output 12A
Signaal PWM-CV

DALI bus standard IEC62386-parts 101, 102, 207.
Output Voltage 10-54Vdc
Output Current Range 150-900mA
Output Power 25W

DALI bus standard IEC62386-parts 101, 102, 207.
Output Voltage 10-54Vdc
Output Current Range200-1200mA
Output Power Range 2W~36W

DALI2 parts 101,102,207
Dimmable 12 V LED driver for constant voltage PWM-CV 75 W
Power 230VAC output 12V

DALI2 parts 101,102,207
Dimmable 24 V LED driver for constant voltage PWM-CV 75 W
Power 230VAC output 24V

DALI2 parts 101,102,207,209
Dimmable 12V LED driver for constant voltage PWM-CV 75W
Power 230VAC output 12V

DALI2 parts 101,102,207,209
Dimmable 24V LED driver for constant voltage PWM-CV 75W
Power 230VAC output 24V

DALI bus standard IEC62386-parts101, 102, 207.
Output Voltage 10-42Vdc
Output Current Range 100-400mA
Output Power Range 1W-12W

Phase dimmer with DALI input to control dimmable 230V luminaires in a DALI system. Available for leading edge, trailing edge or as universal device with automatic load detection. Available as compact 25W version or as 300W version. From Firmware 3.5 onwar

DALI LED-driver (CV) with 4 channels to control RGB or RGBW luminaires via one DALI address (DT8). As alternative to the DT8 control the device also supports the operating modes Colour&Dim and SwitchDim2 (control via 2 switch inputs without DALI). Availab

The DALI-2 RM8 provide a relay contact that can be controlled via the DALI bus to switch continuous loads up to 2kW.

This compact module converts 0-10V input voltages into DALI light levels. Configurations can be made using the DALI Cockpit software. Target address and dimming characteristic can be configured.

Phase dimmer with DALI input to control dimmable 230V luminaires in a DALI system. Available for leading edge, trailing edge or as universal device with automatic load detection. Available as compact 25W version or as 300W version. From Firmware 3.5 onwar

DALI-2 IoT Gateway is an interface to connect the DALI system with smart devices over the Internet of Things (IoT). With the DALI IoT Gateway, a simple realization of an intelligent system is possible, in which devices can be controlled and monitored with

Interface from KNX to DALI, broadcast output to 4 DALI lines, 4 operating devices per DALI line, integrated DALI bus supply, supported applications: color temperature control (DT8: CW-WW), color control (DT8: RGB, RGBW), other (DT0, DT2 , DT3, DT4, DT6),

The DALI USB is used as interface between the DALI Cockpit PC Software and the devices on the DALI bus. It enables the addressing and configuration of DALI installations. The DALI USB is available in 6 different versions: with strain relief, for DIN Rail

DALI PS serves as power supply for the DALI bus system. Standardised voltage and current limitation as well as timing ensure a reliable bus communication. With the output current of up to 250mA and entire DALI line can be supplied. Up to 64 addressable DA

The capacitive 4” colour display with 24-bit colour depth allows both the configuration, as well as the control and operation of a DALI system. Numerous widgets enable customisation. Supported functions are dimming and switching of groups, recall of scene
