theRonda P360-110 DALI SP WIN, 1x slave, 1x impulse, flush, 360°, Ø24m
€209,81 Incl. tax €349,69 Incl. tax. Out of stock, but available
Specifications
Information
theRonda P360-110 DALI SP WIN – DALI-2 Broadcast Presence Detector
Art. No.: 2080055
Product Description
The Theben theRonda P360-110 DALI SP WIN is a high-quality ceiling presence detector for flush mounting with DALI-2 broadcast function. With a circular detection area of 360° and a diameter of up to 24 m (max. 452 m²), the detector is ideal for automatic lighting control and dimming in larger rooms such as offices, schools, and public buildings. The scope of delivery includes preassembled connection cables (0.90 m) and a WAGO WINSTA plug for fast and safe installation.
The detector supports both fully and semi-automatic operation, automatic lighting control with constant light regulation, dimmable light when switching with and without daylight use, as well as orientation light (stand-by function). Commissioning is simple thanks to DALI-2 broadcast, with no need for programming group addresses (Plug & Play). Sensitivity, light value (lux), follow-up time, and detection area are all fully adjustable.
Other features include factory presets, energy management with “eco plus”, learning function, self-learning follow-up time (with shortening for brief presence), scene function, adjustable dimming speed, and extension of the detection area via master/slave or master/master configuration. Correct operation is ensured through mixed light measurement and light measurement correction for fluorescent lamps, halogen/incandescent lamps, energy-saving lamps, and LEDs.
Optional remote controls such as the SendoPro 868-A management remote, the theSenda P installation remote, and the theSenda S user remote are available for quick operation and setting. The device is ready for immediate use and offers IP54 protection (when installed).
Main Features
- Ceiling presence detector for flush mounting, DALI-2 broadcast, 360°, Ø24 m
- With WAGO WINSTA plug and preassembled cables (0.90 m)
- 1x slave output, 1x impulse output for flexible applications
- Automatic lighting control with constant light regulation or switching mode
- Dimmable light when switching with or without daylight influence
- Orientation light (stand-by function) and eco plus energy-saving mode
- Adjustable sensitivity, lux value (10–3000 lx), and follow-up time
- Learning function via remote control or button
- Self-learning follow-up time and shortening with brief presence
- Test mode for fast installation and function check
- Extension of the detection area via master/slave or master/master configuration
- Suitable for fluorescent lamps, halogen/incandescent lamps, energy-saving lamps, and LEDs
- Scene function, adjustable dimming speed, factory presets
- Simple installation without group addressing (Plug & Play)
- IP54 protection (when installed)
Technical Data
Operating voltage | 110 V AC – 230 V AC |
Frequency | 60 Hz |
Mounting height | 1.7 m – 15 m (ideal 3 m) |
Detection area | Ø24 m, 360°, max. 452 m² |
Color | White |
Own consumption | < depends on the load |
Light measurement | Mixed light measurement, adjustable 10–3000 lx |
Lamp types | Incandescent/halogen lamps, fluorescent lamps, energy-saving lamps, LEDs |
Control output | 100 mA |
Light output | DALI interface (IEC SN EN 62 386) for max. 50 DALI devices |
Switching output | DALI |
Protection rating | IP54 (when installed) |
Ambient temperature | Up to 50°C |
Important Notes
- For indoor use only (dry rooms, IP54 when installed).
- Installation only by qualified electricians in accordance with applicable regulations.
- Observe the maximum load and technical specifications to avoid damage.
- Compatible with optional Theben remote controls for easy adjustment.
- Ready for use without complex DALI addressing (DALI-2 broadcast).
