Power Supply PS 24V, 300mA

30,35 Excl. tax €32,38 Excl. tax
€36,72 Incl. tax 39,18 Incl. tax.
In stock (3) Manual
Unit price: €30,35 / Piece
24V DC Netzteil, 300mA, DIN-Schienenmodul mit Status-LED. Umgebungstemperatur: -20°C bis +55°C, Schutzart IP20. Eingangsspannung: 230V AC, Max. Strom: 50mA. Ideal für DALI-2 Displays und IoT Gateways. Abmessungen: 98 x 17.5 x 56 mm. Read more

Specifications

Brand:
Lunatone
Housing:
DIN rail
DALI-2 certified:
No
Article number:
24166012-24HS
EAN:
9010342010118
Availability:
In stock (3)
Delivery time:
1-3 working days

Information

Manuel

24V DC Power Supply, 300mA (Art. Nr. 24166012-24HS)

This high-quality 24V DC power supply with a maximum output current of 300mA is ideal for use in various applications such as DALI-2 displays and IoT gateways. The compact DIN rail module design with status LED offers easy installation and reliable performance.

Technical Specifications

  • Input Voltage: 230V AC
  • Maximum Input Current: 50mA
  • Output Voltage: 24V DC
  • Maximum Output Current: 300mA
  • Dimensions (L x W x H): 98 x 17.5 x 56 mm
  • Protection Degree: IP20
  • Ambient Temperature: -20°C to +55°C
  • Connecting Wire Cross Section: 0.5 ... 2.5 mm²
  • Storage and Transportation Temperature: -20°C to +75°C
  • Protection Class: II
  • Relative Humidity: 15% ... 90% (non-condensing)
  • Stripping Length: 7 mm
  • Mounting: DIN rail

This power supply is CE and UKCA certified and complies with EMC and safety requirements according to EN 61547 and EN 61347-2-11. It is perfect for use in commercial and industrial environments where reliability and safety are paramount.

Applications

  • DALI-2 Display 4"
  • DALI-2 Display 7"
  • DALI 4Net Controller
  • DALI-2 IoT Gateway
  • 4-20mA to DALI Converter
